GC-HS GC-HW Handheld 3D Scanner For Body Furniture

Truly portable and fast scanning speed
Metrology scanner, high accuracy up to 0,02mm
Free to move, scan freely for hard-to-reach areas
Ideal choice for small to large objects' scan

EMAIL

GC-HS GC-HW Handheld 3D Scanner for Body Furniture

It can be used in relief, portrait, craft, art and many other fields.

It is specially use for protecting cultural relics. Compared to traditional technology,

 3D scanner has the advantages of saving data to enrich the databaselow labor costs.

Most important, the shining 3d scanner will not hurt the relics.

3D Laser Scanning is a non-contact, non-destructive technology that digitally

captures the shape of physical objects using a line of laser light. 3D laser

scanners create “point clouds” of data from the surface of an object. Dreambot

Laser 3D Scanner adopt multiple beam laser to obtain 3D point clouds from

object surface, Model up to 0.02mm resolution for high detail.

Model

GC-HS

GC-HW


Standard Mode

Fine Mode

Standard Mode

Fine Mode

Range of view

250mm

100mm

400mm

150mm

Point Distance

0.25mm

0.12mm

0.5mm

0.15mm

Accuracy

0.1mm

0.04mm

0.15mm

0.05mm

Scan Volume

100~2500mm

Working Distance

500mm±30%

Hardware

ONSEMI 1310000pixel 600fps, 8mm Len, TI 1280*800Led

Interface/Voltage

USB 3.0  5A/100~240V 60Hz

Scanning Speed

Non-contact, 1,000,000 points/s, 0.3S/Image

Alignment

Mark align, Feature align, Frame align

Color texture

Support(Optional)

Software

Global register, Wrap, Fill holes, Decimate, Smoothen

PC Require

RAM>16GB; Nvidia GM>4GB;System>Win7 (64bit)

Certification

CE/ FCC / WEEE / CNAS


It is ideal for digitizing medium to large parts such as dies and molds, let you scan small to large objects that are difficult to reach or move, provides the most effective and reliable way to acquire 3D measurements of physical objects, works with our 3D software platform, gathering all scanned data and displaying on software end. Meanwhile, the real time visualization provides a simple, enjoyable scanning experience.

Outstanding features:
* Truly portable and fast scanning speed
* Metrology scanner, high accuracy up to 0,02mm
* Free to move, scan freely for hard-to-reach areas
* Ideal choice for small to large objects' scan
* Customized export file formats
* Compatible to most 3D software
