Einscan H 3D Handheld Scanner with Hybrid LED & Infrared Light Source

Einscan H 3D Handheld Scanner with Hybrid LED & Infrared Light Source

Handheld
Hybrid LED & Infrared Light Source
High precision
Scanning color

Einscan H 3D Handheld Scanner with Hybrid LED & Infrared Light Source

1: Based on years of 3D measurement experience and market demand, we innovatively integrates blue LED light and blue laser into EinScan H handheld 3D scanner.

2: The hybrid laser and LED light sources make EinScan H compatible with a wider range of object sizes, meeting multiple needs of users.

3: High efficiency and reliable result give EinScan H more application possibilities.

Einscan H 3d scanner (18)

Einscan H 3d scanner (13)

Einscan H 3d scanner (10)

Einscan H 3d scanner (8)

Einscan H 3d scanner (19)

Einscan H handheld 3d body scanner for measurements:

Scan Mode	Standard Scan	Body Scan	Face Scan
Light Source	White Light, visible	White Light, visible	Infrared light, invisible
Safety	LED light(eye-safe)	LED light(eye-safe)	CLASS(eye-safe)
Scan Accuracy	Up to 0.05mm	Up to 0.05mm	Up to 0.6mm
Volumetric Accuracy*	0.05+0.1mm/m	0.05+0.1mm/m	/
Scan & Align Speed	1,200,000points/s, 20FPS	1,200,000points/s, 20FPS	720,000points/s, 20FPS
Camera Frame Rate	55FPS
Align Modes	Markers Alignment,Feature Alignment,Hybrid Alignment,Texture Alignment	Feature Alignment	Feature Alignment
Working Distance	470mm
Depth of Field	200-700mm	200-700mm	200-1500mm
Maximum FOV	420mm*440mm	420mm*440mm	780mm*900mm
Point distance	0.25mm-3mm	0.5mm-3mm	0.5mm-3mm
Built-in Color Camera	Yes
Color Scanning	Support
Connection Standard	USB3.0
Output Formats	OBJ;STL;ASC;PLY;P3;3MF
Dimensions	108mm110mm237mm
Weight	703g
Operating Temperature Range	0-40℃
Operating Humidity Range	10-90%
Certifications	CE,FCC,ROHS,WEEE,KC
Recommended Configuration	OS:Win10,64 bit;Graphics card:NVIDIA GTX1080 and higher;Video memory:≥4G;Processor:I7-8700;Memory:≥32GB

Volumetric accuracy refers to the relationship between 3D data accuracy and object size; the accuracy is reduced by 0.1mm per 100cm(standard scan & body scan).

The conclusion is obtained by measuring the center of sphere under marker alignment.

Einscan H 3d scanner (9)

Einscan H 3d scanner (15)

Hybrid Blue Laser & LED Light

Innovatively integrated with dual blue LED light and blue laser, improves scanning materials adaptability with less limitation for a wider range of applications.

LED light scanning allows rapid 3D scanning. Laser scanning, which is less sensitive to ambient light, gives better performance to reflective and dark color surface.

Einscan H 3d scanner (16)

shining 3d scanner Einscan H handheld scanner for scan body :

The high resolution and accuracy meet the needs of most industrial applications for reverse engineering and measuring.

Minimum point distance 0.05 mm

Einscan H 3d scanner (17)

Portable & Easy Operation

EinScan HX is plug and play with user friendly software, which is easy to operate, no matter you are newbie or with professional experience in 3D scanning. The portability and flexibility use of EinScan HX has been considered to its ergonomic design for a more efficient and comfortable scanning experience.
