GC1325ATC Linear tool changer CNC Router For Cabinet Furniture Making

12pcs linear tool magazine
Linear Automatic too changer
9kw ATC spindle
syntec controler

EMAIL

      <


Parameter :



Description

Parameters

X,Y,Z Working Area

1300*2500*300mm

Table Surface

Vacuum with T-slot Table , 7.5kw big power vacuum pump

Frame

Welded Structure

X, Y Structure

25mm 30mmHIWIN linear guide, helical rack

Z Structure

Hiwin Rail Linear guide and TBI Ball Screw

Max. Power Consumption

(Without Spindle)2.5kw~3kw

Spindle Power

9kw HQD or Italy HSD air cooling spindle

Spindle Speed

0-24000RPM

Drive Motors

850w Leadshine servo motor driver

Working Voltage

AC380V/50-60Hz,3PH (Option: 220V/1phase)

Command Language

G Code

Operating System

Weihong NK260 system

Inverter

11kw DELTA inverter or Fuling

Computer Interface

USB

X,Y,Z repositioning Accuracy

±0.02mm

X,Y Resolution

±0.01mm

Software Compatibility

Type3/UcancameV9 Software, (Option: Artcam Software)

Lubrication system

Auto

Tool sensor

Auto

Dust collector

5.5kw double packages dust collector

Reducer

Japanese Shimpo reducer

Optional parts

Japanese YASKAWA servo motor,

Syntec 6MB controller

Rotary device





Features :



9.0kw HSD ATC spindle and carousel tool changing magazine, the machine can change tools automatically during the work. Working area is1300*2500*250mm, widely used in furniture industry.

HSD or HQD 9KW(12 HP ) high frequency automatic tool changer spindle with 8-12 tool linear magazine



Except the spindle, we use high quality components on this machine like Japanese Yaskawa servo motors and servo drivers, Taiwan Hiwin linear rails and TBI ball screw, Taiwan Syntec 6MD control system and so on.

Maintenance free brushless Japan Yaskawa AC servo motors and drives



We also have some optional parts for you to choose: Chinese or Germany Becker vacuum pump, dust collector, mist cooling system, rotary system and so on. Some main parts on the machine can be changed according to your requirements.



Heavy bed body, the bed is treated by the furnace, not easy to deform.



With oil injection system, the drive part of the machine can be effectively lubricated.


Automatic tool calibration pad


6-zone vacuum table


Pneumatic material placement stops


Syntec industrial AC servo controller





 parts

Application:

1. Furniture industry: solidwood doors, composite doors, cabinet doors, interior doors, sofa legs, headboards, antique furniture and superficial flower-shaped engraving of various plate-type furniture and disposable finishing of process.

2. Decorated industry: variety of decorations engraving process such as decorative murals, screens, decorative patterns, three-dimensional wave boards, sound-absorbing panels and so on.

3. Advertising industry: engraving and making for acrylic cutting and engraving, acrylic plastic model making, badges and a variety of logo signs.

4. Arts & crafts industry: sculpture making of arts & crafts such as process relief, shadow carving, craft ornaments, car accessories and so on.


5. Musical instrument industry: headstock processing ,guitar semi-finished products processing, surface sculpture and three-dimensional curved surface making of various musical instruments' decorative patterns.
